Příspěvekod petrik » 24.09.2015 15:26

ahojte
posledne sa mi s rebelom stali tieto tazkosti ze ked dam nieco tlacit tak mi v urcitych intervaloch zastavuje prikladam log subor. nepamatam sa ci to bolo po upgrade repetieru alebo preco vlastne to blbne vodice k termistorom by mali byt v poriadku tie som premeral. a hoci je len pripojena k pc a nic sa nedeje tak donekonecna sa opakuje prikaz M105 *51, M105 *48 ... atd. kabel k tlaciarni som vymenil za novy ten to nerobi. v podstate som si vsimol v tom kode ze to trva 8 sekund to zastavenie :D tlac z karty som neskusal nemam momentalne k dispozicii. tuto temu ak sa Rebel nenahneva budem vyuzivat na moje problemy s tymto strojom :)
do CODE som to nedal preto lebo neviem zachovat v code farebny text a naozaj sa mi nechce nad tym dumat.

00:35:05.605 : Printer reset detected - initalizing
00:35:05.605 : start
00:35:05.816 : N1 M110 *2
00:35:05.816 : N2 M115 *4
00:35:05.816 : N3 M105 *4
00:35:05.816 : N4 M114 *3
00:35:05.857 : N5 M111 S6 *66
00:35:05.859 : N6 T0 *28
00:35:05.859 : N7 M20 *54
00:35:05.860 : N8 M80 *51
00:35:05.860 : N9 M105 *14
00:35:08.231 : Info: 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000
00:35:08.235 : Free RAM:3873
00:35:08.248 : N10 M220 S100 *112
00:35:08.248 : N11 M221 S100 *112
00:35:08.248 : N12 M111 S6 *116
00:35:08.250 : FIRMWARE_NAME:Repetier_0.91 FIRMWARE_URL:https://github.com/repetier/Repetier-Firmware/ PROTOCOL_VERSION:1.0 MACHINE_TYPE:Mendel EXTRUDER_COUNT:1 REPETIER_PROTOCOL:2
00:35:08.256 : Printed filament:357.73m Printing time:3 days 19 hours 7 min
00:35:08.262 : N13 T0 *40
00:35:08.263 : X:0.00 Y:0.00 Z:0.00 E:0.00
00:35:08.264 : Begin file list
00:35:08.264 : End file list
00:35:08.878 : N14 M105 *50
00:35:11.944 : N15 M105 *51
00:35:12.468 : N16 M140 S120 *113
00:35:15.003 : N17 M105 *49
00:35:18.069 : N18 M105 *62
00:35:21.127 : N19 M105 *63
00:35:24.192 : N20 M105 *53
00:35:27.258 : N21 M105 *52
00:35:30.318 : N22 M105 *55
00:35:33.384 : N23 M105 *54
00:35:33.415 : Spuštěn analyzátor objektu...
00:35:33.420 : Objekt je manifold.
00:35:33.423 : Analýza dokončena.
00:35:36.445 : N24 M105 *49
00:35:37.775 : Spuštěn analyzátor objektu...
00:35:37.775 : Objekt je manifold.
00:35:37.775 : Analýza dokončena.
00:35:39.505 : N25 M105 *48
00:35:42.571 : N26 M105 *51
00:35:43.519 : Spuštěn analyzátor objektu...
00:35:43.519 : Objekt je manifold.
00:35:43.519 : Analýza dokončena.
00:35:45.629 : N27 M105 *50
00:35:48.694 : N28 M105 *61
00:35:51.754 : N29 M105 *60
00:35:54.466 : Slic3r command:C:\Program Files\Repetier-Host\Slic3r\slic3r.exe --load "slic3r_settings.ini" --print-center 100.00,100.00 --layer-height 0.2 --cooling --fill-pattern honeycomb --external-fill-pattern rectilinear --fill-density 20.00 -o "composition.gcode" "composition.amf"
00:35:54.815 : N30 M105 *52
00:35:54.951 : <Slic3r> => Processing triangulated mesh
00:35:54.953 : <Slic3r> => Generating perimeters
00:35:55.116 : <Slic3r> => Preparing infill
00:35:55.132 : <Slic3r> => Infilling layers
00:35:55.277 : <Slic3r> => Generating skirt
00:35:55.279 : <Slic3r> => Exporting G-code to composition.gcode
00:35:55.539 : <Slic3r> Done. Process took 0 minutes and 0.593 seconds
00:35:55.540 : <Slic3r> Filament required: 1105.8mm (2.7cm3)
00:35:57.877 : N31 M105 *53
00:36:00.940 : N32 M105 *54
00:36:04.006 : N33 M105 *55
00:36:07.069 : N34 M105 *48
00:36:07.437 : N35 M104 T0 S240 *49
00:36:10.130 : N36 M105 *50
00:36:13.190 : N37 M105 *51
00:36:16.256 : N38 M105 *60
00:36:19.315 : N39 M105 *61
00:36:22.377 : N40 M105 *51
00:36:25.440 : N41 M105 *50
00:36:28.507 : N42 M105 *49
00:36:31.568 : N43 M105 *48
00:36:34.631 : N44 M105 *55
00:36:37.695 : N45 M105 *54
00:36:40.752 : N46 M105 *53
00:36:43.815 : N47 M105 *52
00:36:46.879 : N48 M105 *59
00:36:49.943 : N49 M105 *58
00:36:53.005 : N50 M105 *50
00:36:56.065 : N51 M105 *51
00:36:59.132 : N52 M105 *48
00:37:02.195 : N53 M105 *49
00:37:05.253 : N54 M105 *54
00:37:06.126 : N55 G91 *1
00:37:06.134 : N56 G1 X50 F4800 *44
00:37:06.134 : N57 G90 *2
00:37:07.210 : N58 G91 *12
00:37:07.210 : N59 G1 X50 F4800 *35
00:37:07.210 : N60 G90 *6
00:37:08.317 : N61 M105 *48
00:37:11.377 : N62 M105 *51
00:37:14.443 : N63 M105 *50
00:37:17.507 : N64 M105 *53
00:37:20.570 : N65 M105 *52
00:37:23.633 : N66 M105 *55
00:37:26.696 : N67 M105 *54
00:37:29.754 : N68 M105 *57
00:37:32.818 : N69 M105 *56
00:37:35.877 : N70 M105 *48
00:37:38.944 : N71 M105 *49
00:37:41.859 : N72 G91 *4
00:37:41.859 : N73 G1 Z10 F100 *16
00:37:41.859 : N74 G90 *3
00:37:42.005 : N75 M105 *53
00:37:45.068 : N76 M105 *54
00:37:48.131 : N77 M105 *55
00:37:51.191 : N78 M105 *56
00:37:54.256 : N79 M105 *57
00:37:55.732 : N80 M107 *61
00:37:55.735 : N81 M104 S240 *122
00:37:55.736 : N82 G28 *9
00:37:55.736 : N83 G1 Z5 F5000 *31
00:37:55.736 : N84 M109 S240 *114
00:37:55.736 : N85 G21 *7
00:37:55.736 : N86 G90 *14
00:37:55.736 : N87 M82 *6
00:37:55.736 : N88 G92 E0 *87
00:37:55.736 : N89 G1 E-1 F6000 *32
00:37:55.737 : N90 G92 E0 *94
00:37:55.737 : N91 G1 Z0.3 F7800 *14
00:37:55.742 : N92 G1 X84.473 Y85.589 F7800 *94
00:37:55.844 : N93 M117 ETE 28m 13s *92
00:38:06.460 : X:0.00 Y:0.00 Z:0.00 E:0.00
00:38:06.460 : N94 M105 *58
00:38:28.294 : N95 M117 ETE 28m 13s *90
00:38:28.295 : N96 M105 *56
00:38:28.295 : N97 G1 E1 F6000 *2
00:38:28.296 : Tisky vrstvy 1 z 50
00:38:28.296 : N98 G1 X86.241 Y84.011 E1.15833 F1080 *20
00:38:28.296 : N99 G1 X88.431 Y83.105 E1.31666 *126
00:38:28.298 : N100 G1 X90 Y82.929 E1.42216 *94
00:38:28.412 : N101 M117 ETE 28m 13s *102
00:38:28.415 : N102 G1 X110 Y82.929 E2.75826 *107
00:38:28.598 : N103 G1 X112.337 Y83.326 E2.91659 *121
00:38:28.598 : N104 G1 X114.411 Y84.473 E3.07492 F1080 *31
00:38:28.602 : N105 G1 X115.989 Y86.241 E3.23325 *116
00:38:28.606 : N106 G1 X116.895 Y88.431 E3.39159 *117
00:38:28.614 : N107 G1 X117.071 Y90 E3.49708 *99
00:38:28.987 : N108 G1 X117.071 Y110 E4.83319 *80
00:38:28.991 : N109 G1 X116.674 Y112.337 E4.99152 *78
00:38:28.999 : N110 G1 X115.527 Y114.411 E5.14985 *67
00:38:29.003 : N111 G1 X113.759 Y115.989 E5.30818 *65
00:38:29.011 : N112 G1 X111.569 Y116.895 E5.46651 *76
00:38:29.020 : N113 G1 X110 Y117.071 E5.57201 *90
00:38:29.027 : N114 G1 X90 Y117.071 E6.90811 *103
00:38:29.031 : N115 G1 X87.663 Y116.674 E7.06644 *127
00:38:29.040 : N116 G1 X85.589 Y115.527 E7.22477 *123
00:38:29.052 : N117 G1 X84.011 Y113.759 E7.3831 *79
00:38:29.060 : N118 G1 X83.105 Y111.569 E7.54143 *126
00:38:29.060 : N119 G1 X82.929 Y110 E7.64693 *100
00:38:30.064 : N120 G1 X82.929 Y90 E8.98304 *80
00:38:31.108 : N121 M105 *5
00:38:31.109 : N122 G1 X83.326 Y87.663 E9.14137 *74
00:38:31.171 : N123 G1 X84.444 Y85.642 E9.29569 *79
00:38:31.301 : N124 G1 X84.956 Y85.87 F7800 *83
00:38:31.444 : N125 G1 X85.004 Y85.787 E9.3021 F1080 *30
00:38:31.543 : N126 G1 X86.753 Y84.328 E9.45427 *68
00:38:32.665 : N127 G1 X90 Y83.464 E9.6787 *107
00:38:32.952 : N128 G1 X110 Y83.464 E11.01481 *86
00:38:32.959 : N129 G1 X112.243 Y83.861 E11.16698 *75
00:38:33.111 : N130 G1 X114.213 Y85.004 E11.31915 F1080 *45
00:38:33.235 : N131 G1 X115.672 Y86.753 E11.47132 *75
00:38:33.333 : N132 G1 X116.536 Y90 E11.69575 *91
00:38:34.454 : N133 M117 ETE 28m 04s *97
00:38:34.598 : N134 M105 *1
00:38:34.742 : N135 G1 X116.536 Y110 E13.03186 *99
00:38:34.881 : N136 G1 X116.139 Y112.243 E13.18403 *112
00:38:34.881 : N137 G1 X114.996 Y114.213 E13.3362 *71
00:38:35.024 : N138 G1 X113.247 Y115.672 E13.48837 *126
00:38:35.122 : N139 G1 X110 Y116.536 E13.7128 *95
00:38:36.244 : N140 G1 X90 Y116.536 E15.04891 *86
00:38:36.526 : N141 G1 X87.757 Y116.139 E15.20108 *78
00:38:36.526 : N142 G1 X85.787 Y114.996 E15.35325 *68
00:38:36.532 : N143 G1 X84.328 Y113.247 E15.50543 *64
00:38:36.670 : N144 G1 X83.464 Y110 E15.72985 *85
00:38:36.814 : N145 G1 X83.464 Y90 E17.06596 *98
00:38:36.912 : N146 G1 X83.861 Y87.757 E17.21813 *112
00:38:38.034 : N147 M105 *5
00:38:38.034 : N148 G1 X84.926 Y85.921 E17.35989 *113
00:38:38.178 : N149 G1 E16.35989 F6000 *22
00:38:38.317 : N150 G92 E0 *99
00:38:38.350 : N151 G1 X106.371 Y106.371 F7800 *101
00:38:38.350 : N152 G1 E1 F6000 *58
00:38:38.498 : N153 M117 ETE 27m 58s *97
00:38:38.698 : N154 G1 X93.629 Y106.371 E1.85127 F540 *40
00:38:39.820 : N155 G1 X93.629 Y93.629 E2.70253 *66
00:38:39.955 : N156 G1 X106.371 Y93.629 E3.5538 *77
00:38:40.201 : N157 M105 *4
00:38:40.201 : N158 G1 X106.371 Y106.311 E4.40106 *79
00:38:40.226 : N159 G1 X105.836 Y105.836 F7800 *109
00:38:40.554 : N160 G1 X94.164 Y105.836 E5.18076 F540 *40
00:38:40.554 : N161 G1 X94.164 Y94.164 E5.96046 *76
00:38:40.554 : N162 G1 X105.836 Y94.164 E6.74016 *114
00:38:41.545 : N163 G1 X105.836 Y105.776 E7.51586 *69
00:38:41.823 : N164 G1 X105.3 Y105.3 F7800 *99
00:38:41.830 : N165 G1 X94.7 Y105.3 E8.22399 F378 *44
00:38:41.959 : N166 G1 X94.7 Y94.7 E8.93213 *65
00:38:42.155 : N167 G1 X105.3 Y94.7 E9.64027 *113
00:38:43.277 : N168 M105 *8
00:38:43.277 : N169 G1 X105.3 Y105.24 E10.3444 *127
00:38:43.552 : N170 M117 ETE 27m 39s *103
00:38:43.687 : N171 G1 X105.3 Y105.7 F7800 *99
00:38:43.687 : N172 G1 X108.629 Y108.629 F7800 *100
00:38:45.010 : N173 G1 X91.371 Y108.629 E11.49729 F540 *24
00:38:45.149 : N174 G1 X91.371 Y91.371 E12.65019 *120
00:38:45.382 : N175 G1 X108.629 Y91.371 E13.80309 *72
00:38:45.390 : N176 G1 X108.629 Y108.569 E14.95197 *115
00:38:53.209 : N177 M105 *6
00:38:53.213 : N178 M117 ETE 27m 31s *103
00:38:53.586 : N179 M117 ETE 27m 31s *102
00:39:01.360 : N180 M105 *14
00:39:01.360 : N181 M117 ETE 27m 31s *97
00:39:02.871 : N182 M105 *12
00:39:04.248 : N183 M117 ETE 27m 31s *99
00:39:05.669 : N184 M105 *10
00:39:07.082 : N185 G1 X109.164 Y109.164 F7800 *108
00:39:07.200 : N186 G1 X90.836 Y109.164 E16.17643 F540 *21
00:39:07.315 : N187 G1 X90.836 Y90.836 E17.40089 *127
00:39:07.319 : N188 G1 X109.164 Y90.836 E18.62535 *66
00:39:07.440 : N189 G1 X109.164 Y109.104 E19.84581 *124
00:39:07.440 : N190 G1 X109.7 Y109.7 F7800 *104
00:39:07.558 : N191 G1 X90.3 Y109.7 E21.14183 F378 *24
00:39:07.563 : N192 G1 X90.3 Y90.3 E22.43786 *118
00:39:07.565 : N193 G1 X109.7 Y90.3 E23.73388 *74
00:39:08.421 : N194 M105 *11
00:39:08.421 : N195 G1 X109.7 Y109.64 E25.0259 *115
00:39:11.059 : N196 M117 ETE 27m 09s *108
00:39:11.059 : N197 M105 *8
00:39:12.316 : N198 G1 X109.354 Y109.5 F7800 *103
00:39:12.352 : N199 G1 X106.693 Y106.313 F7800 *108
00:39:14.053 : N200 M117 ETE 27m 09s *96
00:39:14.053 : N201 M105 *4
00:39:17.407 : N202 M105 *7
00:39:17.412 : N203 G1 X108.307 Y107.927 E25.17898 F1080 *19
00:39:17.413 : N204 G1 X108.307 Y107.167 E25.22997 *127
00:39:19.340 : N205 M117 ETE 27m 09s *101
00:39:19.343 : N206 G1 X106.693 Y105.552 E25.38305 *113
00:39:19.349 : N207 G1 X106.693 Y104.792 E25.43403 *114
00:39:19.469 : N208 G1 X108.307 Y106.406 E25.58712 *126
00:39:19.473 : N209 G1 X108.307 Y105.646 E25.6381 *79
00:39:19.473 : N210 G1 X106.693 Y104.032 E25.79119 *126
00:39:21.147 : N211 M105 *5
00:39:21.147 : N212 G1 X106.693 Y103.271 E25.84217 *113
00:39:23.297 : N213 M105 *7
00:39:23.298 : N214 G1 X108.307 Y104.886 E25.99525 *126
00:39:24.993 : N215 M117 ETE 27m 08s *101
00:39:26.906 : N216 M105 *2
00:39:26.906 : N217 G1 X108.307 Y104.125 E26.04624 *120
00:39:26.953 : N218 G1 X106.693 Y102.511 E26.19932 *112
00:39:31.027 : N219 M117 ETE 27m 08s *105
00:39:31.027 : N220 M105 *7
00:39:33.066 : N221 M105 *6
00:39:33.066 : N222 G1 X106.693 Y101.751 E26.25031 *121
00:39:33.080 : N223 G1 X108.307 Y103.365 E26.40339 *119
00:39:35.220 : N224 M117 ETE 27m 08s *103
00:39:35.225 : N225 G1 X108.307 Y102.605 E26.45437 *127
00:39:35.225 : N226 G1 X106.693 Y100.99 E26.60746 *73
00:39:38.333 : N227 M105 *0
00:39:38.341 : N228 G1 X106.693 Y100.23 E26.65844 *78
00:39:38.345 : N229 G1 X108.307 Y101.844 E26.81153 *116
00:39:38.346 : N230 G1 X108.307 Y101.084 E26.86251 *126
00:39:41.306 : N231 M105 *7
00:39:44.502 : N232 M117 ETE 27m 07s *111
00:39:44.502 : N233 M105 *5
00:39:44.502 : N234 G1 X106.693 Y99.47 E27.01559 *114
00:39:47.491 : N235 M105 *3
00:39:47.491 : N236 M117 ETE 27m 07s *107
00:39:47.498 : N237 G1 X106.693 Y98.709 E27.06658 *72
00:39:47.593 : N238 M105 *14
00:39:47.725 : N239 G1 X108.307 Y100.324 E27.21966 *124
00:39:47.778 : N240 G1 X108.307 Y99.563 E27.27065 *74
00:39:48.034 : N241 G1 X106.693 Y97.949 E27.42373 *64
00:39:48.037 : N242 G1 X106.693 Y97.189 E27.47472 *68
00:39:48.041 : N243 G1 X108.307 Y98.803 E27.6278 *126
00:39:48.164 : N244 G1 X108.307 Y98.043 E27.67878 *72
00:39:48.171 : N245 G1 X106.693 Y96.428 E27.83187 *75
00:39:48.175 : N246 G1 X106.693 Y95.668 E27.88285 *71
00:39:48.179 : N247 G1 X108.307 Y97.282 E28.03594 *73
00:39:48.183 : N248 G1 X108.307 Y96.522 E28.08692 *68
00:39:48.290 : N249 G1 X106.693 Y94.908 E28.24 *118
00:39:48.343 : N250 G1 X106.693 Y94.147 E28.29099 *64
00:39:48.478 : N251 G1 X108.307 Y95.762 E28.44407 *79
00:39:48.531 : N252 G1 X108.307 Y91.96 F7800 *111
00:39:48.667 : N253 G1 X108.04 Y91.693 E28.46942 F1080 *23
00:39:48.720 : N254 G1 X107.28 Y91.693 E28.5204 *64
00:39:48.855 : N255 G1 X108.307 Y92.72 E28.61785 *116
00:39:48.908 : N256 G1 X108.307 Y93.481 E28.66883 *64
00:39:49.126 : N257 G1 X106.519 Y91.693 E28.83838 *78
00:39:49.130 : N258 G1 X105.759 Y91.693 E28.88937 *65
00:39:49.232 : N259 G1 X108.307 Y94.241 E29.13102 *65
00:39:49.285 : N260 G1 X108.307 Y95.001 E29.18201 *71
00:39:49.420 : N261 G1 X104.999 Y91.693 E29.49576 *77
00:39:49.482 : N262 G1 X104.238 Y91.693 E29.54675 *66
00:39:49.609 : N263 M117 ETE 27m 05s *105
00:39:49.662 : N264 G1 X105.853 Y93.307 E29.69983 *64
00:39:49.822 : N265 G1 X105.092 Y93.307 E29.75082 *65
00:39:49.850 : N266 G1 X103.478 Y91.693 E29.9039 *117
00:39:49.986 : N267 G1 X102.718 Y91.693 E29.95488 *75
00:39:50.039 : N268 G1 X104.332 Y93.307 E30.10797 *76
00:39:50.174 : N269 G1 X103.572 Y93.307 E30.15895 *64
00:39:50.349 : N270 G1 X101.957 Y91.693 E30.31204 *79
00:39:50.350 : N271 G1 X101.197 Y91.693 E30.36302 *74
00:39:50.362 : N272 G1 X102.811 Y93.307 E30.5161 *112
00:39:50.416 : N273 G1 X102.051 Y93.307 E30.56709 *67
00:39:50.551 : N274 G1 X100.437 Y91.693 E30.72017 *70
00:39:50.605 : N275 G1 X99.676 Y91.693 E30.77116 *116
00:39:50.735 : N276 M105 *4
00:39:50.735 : N277 G1 X101.291 Y93.307 E30.92424 *78
00:39:50.927 : N278 G1 X100.53 Y93.307 E30.97523 *127
00:39:50.936 : N279 G1 X98.916 Y91.693 E31.12831 *126
00:39:50.940 : N280 G1 X98.156 Y91.693 E31.17929 *121
00:39:51.019 : N281 G1 X99.77 Y93.307 E31.33238 *76
00:39:51.075 : N282 G1 X99.01 Y93.307 E31.38336 *74
00:39:51.276 : N283 G1 X97.395 Y91.693 E31.53645 *125
00:39:51.282 : N284 G1 X96.635 Y91.693 E31.58743 *120
00:39:51.485 : N285 G1 X98.249 Y93.307 E31.74051 *120
00:39:51.538 : N286 G1 X97.489 Y93.307 E31.7915 *67
00:39:51.805 : N287 G1 X95.875 Y91.693 E31.94458 *123
00:39:51.858 : N288 G1 X95.114 Y91.693 E31.99557 *121
00:39:52.021 : N289 G1 X96.729 Y93.307 E32.14865 *115
00:39:52.046 : N290 G1 X95.968 Y93.307 E32.19963 *121
00:39:52.181 : N291 G1 X94.354 Y91.693 E32.35272 *115
00:39:52.234 : N292 G1 X93.594 Y91.693 E32.4037 *76
00:39:52.370 : N293 G1 X95.208 Y93.307 E32.55679 *123
00:39:52.423 : N294 G1 X94.448 Y93.307 E32.60777 *118
00:39:52.558 : N295 G1 X92.833 Y91.693 E32.76085 *118
00:39:52.611 : N296 G1 X92.073 Y91.693 E32.81184 *113
00:39:52.746 : N297 G1 X93.687 Y93.307 E32.96492 *114
00:39:52.800 : N298 G1 X93.307 Y93.687 F7800 *110
00:39:52.935 : N299 G1 X91.693 Y92.073 E33.11801 F1080 *29
00:39:52.988 : N300 G1 X91.693 Y92.833 E33.16899 *121
00:39:53.123 : N301 G1 X93.307 Y94.448 E33.32207 *127
00:39:53.177 : N302 G1 X93.307 Y95.208 E33.37306 *122
00:39:53.312 : N303 G1 X91.693 Y93.594 E33.52614 *112
00:39:53.365 : N304 G1 X91.693 Y94.354 E33.57713 *121
00:39:53.500 : N305 G1 X93.307 Y95.968 E33.73021 *118
00:39:53.553 : N306 G1 X93.307 Y96.729 E33.7812 *70
00:39:53.689 : N307 G1 X91.693 Y95.114 E33.93428 *126
00:39:53.737 : N308 M105 *12
00:39:53.738 : N309 G1 X91.693 Y95.875 E33.98526 *122
00:39:53.917 : N310 G1 X93.307 Y97.489 E34.13835 *126
00:39:53.925 : N311 G1 X93.307 Y98.249 E34.18933 *118
00:39:54.061 : N312 G1 X91.693 Y96.635 E34.34242 *125
00:39:54.115 : N313 G1 X91.693 Y97.395 E34.3934 *76
00:39:54.250 : N314 G1 X93.307 Y99.01 E34.54648 *71
00:39:54.438 : N315 G1 X93.307 Y99.77 E34.59747 *68
00:39:54.446 : N316 G1 X91.693 Y98.156 E34.75055 *116
00:39:54.495 : N317 G1 X91.693 Y98.916 E34.80154 *115
00:39:54.626 : N318 M117 ETE 27m 00s *97
00:39:54.680 : N319 G1 X93.307 Y100.53 E34.95462 *123
00:39:54.815 : N320 G1 X93.307 Y101.291 E35.0056 *114
00:39:54.868 : N321 G1 X91.693 Y99.676 E35.15869 *116
00:39:55.016 : N322 G1 X91.693 Y100.437 E35.20967 *72
00:39:55.036 : N323 G1 X93.307 Y102.051 E35.36276 *73
00:39:55.171 : N324 G1 X93.307 Y102.811 E35.41374 *65
00:39:55.343 : N325 G1 X91.693 Y101.197 E35.56682 *68
00:39:55.343 : N326 G1 X91.693 Y101.957 E35.61781 *69
00:39:55.359 : N327 G1 X93.307 Y103.572 E35.77089 *79
00:39:55.412 : N328 G1 X93.307 Y104.332 E35.82188 *79
00:39:55.544 : N329 G1 X91.693 Y102.718 E35.97496 *64
00:39:55.607 : N330 G1 X91.693 Y103.478 E36.02595 *65
00:39:55.732 : N331 G1 X93.307 Y105.092 E36.17903 *75
00:39:55.785 : N332 G1 X93.307 Y105.853 E36.23001 *65
00:39:55.920 : N333 G1 X91.693 Y104.238 E36.3831 *117
00:39:55.974 : N334 G1 X91.693 Y104.999 E36.43408 *64
00:39:56.113 : N335 G1 X93.307 Y106.613 E36.58717 *67
00:39:56.162 : N336 G1 X95.001 Y108.307 E36.74784 *73
00:39:56.297 : N337 G1 X95.762 Y108.307 E36.79882 *78
00:39:56.351 : N338 G1 X94.147 Y106.693 E36.95191 *78
00:39:56.486 : N339 G1 X94.908 Y106.693 E37.00289 *75
00:39:56.539 : N340 G1 X96.522 Y108.307 E37.15597 *73
00:39:56.674 : N341 G1 X97.282 Y108.307 E37.20696 *64
00:39:56.727 : N342 G1 X95.668 Y106.693 E37.36004 *77
00:39:56.862 : N343 M105 *3
00:39:56.863 : N344 G1 X96.428 Y106.693 E37.41103 *72
00:39:56.918 : N345 G1 X98.043 Y108.307 E37.56411 *72
00:39:57.051 : N346 G1 X98.803 Y108.307 E37.61509 *75
00:39:57.215 : N347 G1 X97.189 Y106.693 E37.76818 *67
00:39:57.247 : N348 G1 X97.949 Y106.693 E37.81916 *79
00:39:57.292 : N349 G1 X99.563 Y108.307 E37.97225 *78
00:39:57.481 : N350 G1 X100.324 Y108.307 E38.02323 *118
00:39:57.488 : N351 G1 X98.709 Y106.693 E38.17631 *72
00:39:57.616 : N352 G1 X99.47 Y106.693 E38.2273 *65
00:39:57.669 : N353 G1 X101.084 Y108.307 E38.38038 *125
00:39:57.805 : N354 G1 X101.844 Y108.307 E38.43137 *124
00:39:57.858 : N355 G1 X100.23 Y106.693 E38.58445 *73
00:39:58.013 : N356 G1 X100.99 Y106.693 E38.63544 *67
00:39:58.046 : N357 G1 X102.605 Y108.307 E38.78852 *117
00:39:58.181 : N358 G1 X103.365 Y108.307 E38.8395 *79
00:39:58.236 : N359 G1 X101.751 Y106.693 E38.99259 *112
00:39:58.369 : N360 G1 X102.511 Y106.693 E39.04357 *117
00:39:58.509 : N361 G1 X104.125 Y108.307 E39.19666 *124
00:39:58.563 : N362 G1 X104.886 Y108.307 E39.24764 *114
00:39:58.698 : N363 G1 X103.271 Y106.693 E39.40072 *114
00:39:58.751 : N364 G1 X104.032 Y106.693 E39.45171 *112
00:39:58.886 : N365 G1 X105.646 Y108.307 E39.60479 *121
00:39:58.939 : N366 G1 X106.406 Y108.307 E39.65578 *122
00:39:59.115 : N367 G1 X104.792 Y106.693 E39.80886 *118
00:39:59.127 : N368 G1 X105.552 Y106.693 E39.85984 *112
00:39:59.262 : N369 G1 X107.167 Y108.307 E40.01293 *120
00:39:59.316 : N370 G1 X107.927 Y108.307 E40.06391 *120
00:39:59.451 : N371 G1 X106.313 Y106.693 E40.217 *122
00:39:59.505 : N372 G1 X94.241 Y108.307 F7800 *81
00:39:59.640 : N373 M117 ETE 26m 55s *109
00:39:59.693 : N374 G1 X91.693 Y105.759 E40.45865 F1080 *40
00:39:59.828 : N375 M105 *6
00:39:59.881 : N376 G1 X91.693 Y106.519 E40.50963 *67
00:40:00.016 : N377 G1 X93.481 Y108.307 E40.67918 *78
00:40:00.070 : N378 G1 X92.72 Y108.307 E40.73016 *122
00:40:00.209 : N379 G1 X91.693 Y107.28 E40.82761 *121
00:40:00.209 : N380 G1 X91.693 Y108.04 E40.87859 *127
00:40:00.377 : N381 G1 X91.96 Y108.307 E40.90393 *118
00:40:00.377 : N382 M106 S255 *76
00:40:00.389 : N383 G1 E39.90393 F6000 *17
00:40:00.397 : N384 G92 E0 *104
00:40:00.442 : N385 G1 Z0.5 F7800 *62
00:40:00.577 : N386 G1 X106.321 Y106.321 F7800 *109
00:40:00.578 : N387 G1 E1 F6000 *48
00:40:00.765 : Tisky vrstvy 2 z 50
00:40:00.766 : N388 G1 X93.679 Y106.321 E1.66048 F1030.475 *5
00:40:00.820 : N389 G1 X93.679 Y93.679 E2.32096 *76
00:40:00.954 : N390 G1 X106.321 Y93.679 E2.98145 *126
00:40:01.007 : N391 G1 X106.321 Y106.261 E3.63879 *76
00:40:01.007 : N392 G1 X105.693 Y105.693 F7800 *104
00:40:01.139 : N393 G1 X94.307 Y105.693 E4.23362 F1030.475 *4
00:40:01.307 : N394 G1 X94.307 Y94.307 E4.82845 *75
00:40:01.327 : N395 G1 X105.693 Y94.307 E5.42328 *118
00:40:01.380 : N396 G1 X105.693 Y105.633 E6.01497 *73
00:40:01.515 : N397 G1 X105.2 Y105.2 F7800 *109
00:40:01.569 : N398 G1 X94.8 Y105.2 E6.32376 F721.333 *57
00:40:01.704 : N399 G1 X94.8 Y94.8 E6.63255 *64
00:40:01.913 : N400 G1 X105.2 Y94.8 E6.94134 *120
00:40:02.122 : N401 G1 X105.2 Y105.14 E7.24835 *127
00:40:02.176 : N402 G1 X105.2 Y105.6 F7800 *98
00:40:02.322 : N403 G1 X108.679 Y108.679 F7800 *103
00:40:02.375 : N404 G1 X91.321 Y108.679 E8.15522 F1030.475 *14
00:40:02.466 : N405 G1 X91.321 Y91.321 E9.06208 *70
00:40:02.519 : N406 G1 X108.679 Y91.321 E9.96895 *123
00:40:02.547 : N407 G1 X108.679 Y108.619 E10.87268 *117
00:40:10.379 : N408 M105 *11
00:40:10.579 : N409 M117 ETE 26m 40s *99
00:40:10.809 : N410 M117 ETE 26m 40s *107
00:40:18.640 : N411 M105 *3
00:40:18.640 : N412 M117 ETE 26m 40s *105
00:40:19.435 : N413 G1 X109.307 Y109.307 F7800 *102
00:40:20.180 : N414 G1 X90.693 Y109.307 E11.8452 F1030.475 *13
00:40:21.786 : N415 M117 ETE 26m 39s *96
00:40:21.786 : N416 M105 *4
00:40:21.917 : N417 G1 X90.693 Y90.693 E12.81771 *123
00:40:22.057 : N418 G1 X109.307 Y90.693 E13.79023 *75
00:40:22.179 : N419 G1 X109.307 Y109.247 E14.75961 *114
00:40:22.183 : N420 G1 X109.8 Y109.8 F7800 *102
00:40:22.183 : N421 G1 X90.2 Y109.8 E15.34156 F721.333 *0
00:40:22.183 : N422 G1 X90.2 Y90.2 E15.92351 *126
00:40:22.647 : N423 G1 X109.8 Y90.2 E16.50546 *73
00:40:22.647 : N424 G1 X109.8 Y109.74 E17.08563 *69
00:40:23.052 : N425 G1 X109.454 Y109.6 F7800 *96
00:40:23.723 : N426 G1 X107.992 Y108.298 F7800 *110
00:40:24.395 : N427 M105 *6
00:40:24.395 : N428 G1 X108.298 Y107.992 E17.1087 F2060.95 *10
00:40:24.432 : N429 G1 X108.298 Y107.087 E17.15686 *116
00:40:25.300 : N430 G1 X107.087 Y108.298 E17.24803 *125
00:40:27.036 : N431 M117 ETE 26m 28s *102
00:40:27.905 : N432 M105 *2
00:40:27.905 : N433 G1 X106.182 Y108.298 E17.29618 *114
00:40:28.044 : N434 G1 X108.298 Y106.182 E17.45545 *116
00:40:28.045 : N435 G1 X108.298 Y105.277 E17.50361 *123
00:40:28.052 : N436 G1 X105.277 Y108.298 E17.73098 *124
00:40:29.068 : N437 G1 X104.372 Y108.298 E17.77914 *113
00:40:30.088 : N438 G1 X105.968 Y106.702 E17.89927 *119
00:40:31.246 : N439 M105 *9
00:40:31.246 : N440 M117 ETE 26m 28s *96
00:40:31.246 : N441 G1 X105.063 Y106.702 E17.94742 *122
00:40:32.128 : N442 G1 X103.467 Y108.298 E18.06756 *118
00:40:32.173 : N443 G1 X102.562 Y108.298 E18.11571 *115
00:40:33.267 : N444 G1 X104.158 Y106.702 E18.23584 *124
00:40:34.363 : N445 M105 *2
00:40:35.458 : N446 G1 X103.253 Y106.702 E18.284 *119
00:40:36.551 : N447 M117 ETE 26m 28s *103
00:40:36.673 : N448 M105 *15
00:40:36.678 : N449 G1 X101.657 Y108.298 E18.40413 *126
00:40:36.678 : N450 G1 X100.752 Y108.298 E18.45229 *121
00:40:38.222 : N451 G1 X102.348 Y106.702 E18.57242 *115
00:40:39.861 : N452 M105 *4
00:40:41.499 : N453 M117 ETE 26m 28s *98
00:40:41.506 : N454 G1 X101.443 Y106.702 E18.62057 *121
00:40:43.251 : N455 M105 *3
00:40:43.259 : N456 G1 X99.847 Y108.298 E18.74071 *72
00:40:43.262 : N457 G1 X98.942 Y108.298 E18.78886 *64
00:40:43.268 : N458 G1 X100.538 Y106.702 E18.90899 *126
00:40:43.276 : N459 G1 X99.633 Y106.702 E18.95715 *72
00:40:43.281 : N460 G1 X98.037 Y108.298 E19.07728 *77
00:40:43.416 : N461 G1 X97.132 Y108.298 E19.12544 *75
00:40:43.426 : N462 G1 X98.728 Y106.702 E19.24557 *69
00:40:43.428 : N463 G1 X97.823 Y106.702 E19.29372 *67
00:40:43.436 : N464 G1 X96.227 Y108.298 E19.41386 *70
00:40:43.436 : N465 G1 X95.322 Y108.298 E19.46201 *73
00:40:43.530 : N466 G1 X96.918 Y106.702 E19.58214 *73
00:40:43.579 : N467 G1 X96.013 Y106.702 E19.6303 *118
00:40:43.724 : N468 G1 X94.417 Y108.298 E19.75043 *64
00:40:43.776 : N469 G1 X93.512 Y108.298 E19.79859 *77
00:40:43.862 : N470 G1 X95.108 Y106.702 E19.91872 *75
00:40:43.911 : N471 G1 X94.203 Y106.702 E19.96687 *64
00:40:44.075 : N472 G1 X92.607 Y108.298 E20.08701 *79
00:40:44.083 : N473 G1 X91.722 Y108.278 E20.13411 *77
00:40:44.132 : N474 G1 X93.298 Y106.702 E20.25274 *74
00:40:44.181 : N475 G1 X93.298 Y105.797 E20.30089 *64
00:40:44.268 : N476 G1 X91.702 Y107.393 E20.42102 *66
00:40:44.320 : N477 G1 X91.702 Y106.488 E20.46918 *72
00:40:44.403 : N478 G1 X93.298 Y104.892 E20.58931 *66
00:40:44.456 : N479 G1 X93.298 Y103.987 E20.63747 *70
00:40:44.538 : N480 G1 X91.702 Y105.583 E20.7576 *120
00:40:44.591 : N481 G1 X91.702 Y104.678 E20.80575 *67
00:40:44.673 : N482 G1 X93.298 Y103.082 E20.92589 *64
00:40:44.726 : N483 G1 X93.298 Y102.177 E20.97404 *74
00:40:44.812 : N484 G1 X91.702 Y103.773 E21.09417 *78
00:40:44.861 : N485 G1 X91.702 Y102.868 E21.14233 *71
00:40:44.947 : N486 G1 X93.298 Y101.272 E21.26246 *65
00:40:44.997 : N487 G1 X93.298 Y100.367 E21.31061 *69
00:40:45.173 : N488 G1 X91.702 Y101.963 E21.43075 *65
00:40:45.181 : N489 G1 X91.702 Y101.058 E21.4789 *118
00:40:45.217 : N490 G1 X93.298 Y99.462 E21.59904 *116
00:40:45.271 : N491 G1 X93.298 Y98.557 E21.64719 *127
00:40:45.353 : N492 G1 X91.702 Y100.153 E21.76732 *66
00:40:45.406 : N493 G1 X91.702 Y99.248 E21.81548 *124
00:40:45.489 : N494 G1 X93.298 Y97.652 E21.93561 *118
00:40:45.541 : N495 G1 X93.298 Y96.747 E21.98376 *120
00:40:45.628 : N496 G1 X91.702 Y98.343 E22.1039 *74
00:40:45.677 : N497 G1 X91.702 Y97.438 E22.15205 *119
00:40:45.758 : N498 M105 *2
00:40:45.758 : N499 G1 X93.298 Y95.842 E22.27218 *115
00:40:45.815 : N500 G1 X93.298 Y94.937 E22.32034 *120
00:40:45.893 : N501 M117 ETE 26m 25s *105
00:40:45.947 : N502 G1 X91.702 Y96.533 E22.44047 *113
00:40:46.034 : N503 G1 X91.702 Y95.628 E22.48863 *120
00:40:46.082 : N504 G1 X93.298 Y94.032 E22.60876 *121
00:40:46.279 : N505 G1 X93.127 Y93.298 E22.64885 *114
00:40:46.286 : N506 G1 X94.723 Y91.702 E22.76898 *127
00:40:46.303 : N507 G1 X93.818 Y91.702 E22.81714 *125
00:40:46.487 : N508 G1 X91.702 Y93.818 E22.9764 *69
00:40:46.495 : N509 G1 X91.702 Y94.723 E23.02456 *124
00:40:46.499 : N510 G1 X93.298 Y93.127 E23.14469 *126
00:40:46.503 : N511 G1 X94.032 Y93.298 E23.18478 *113
00:40:46.578 : N512 G1 X95.628 Y91.702 E23.30491 *119
00:40:46.627 : N513 G1 X96.533 Y91.702 E23.35307 *113
00:40:46.708 : N514 G1 X94.937 Y93.298 E23.4732 *72
00:40:46.762 : N515 G1 X95.842 Y93.298 E23.52136 *122
00:40:46.844 : N516 G1 X97.438 Y91.702 E23.64149 *115
00:40:46.904 : N517 G1 X98.343 Y91.702 E23.68964 *125
00:40:46.983 : N518 G1 X96.747 Y93.298 E23.80978 *115
00:40:47.167 : N519 G1 X97.652 Y93.298 E23.85793 *120
00:40:47.175 : N520 G1 X99.248 Y91.702 E23.97806 *119
00:40:47.179 : N521 G1 X100.153 Y91.702 E24.02622 *77
00:40:47.254 : N522 G1 X98.557 Y93.298 E24.14635 *123
00:40:47.303 : N523 G1 X99.462 Y93.298 E24.19451 *113
00:40:47.388 : N524 G1 X101.058 Y91.702 E24.31464 *67
00:40:47.451 : N525 G1 X101.963 Y91.702 E24.36279 *78
00:40:47.524 : N526 G1 X100.367 Y93.298 E24.48293 *75
00:40:47.577 : N527 G1 X101.272 Y93.298 E24.53108 *69
00:40:47.659 : N528 G1 X102.868 Y91.702 E24.65121 *66
00:40:47.704 : N529 G1 X103.773 Y91.702 E24.69937 *68
00:40:47.790 : N530 G1 X102.177 Y93.298 E24.8195 *124
00:40:47.844 : N531 G1 X103.082 Y93.298 E24.86766 *75
00:40:47.949 : N532 G1 X104.678 Y91.702 E24.98779 *73
00:40:48.000 : N533 G1 X105.583 Y91.702 E25.03594 *76
00:40:48.085 : N534 G1 X103.987 Y93.298 E25.15608 *64
00:40:48.265 : N535 G1 X104.892 Y93.298 E25.20423 *78
00:40:48.273 : N536 G1 X106.488 Y91.702 E25.32436 *75
00:40:48.277 : N537 G1 X107.393 Y91.702 E25.37252 *71
00:40:48.351 : N538 G1 X105.797 Y93.298 E25.49265 *67
00:40:48.401 : N539 G1 X106.702 Y93.298 E25.54081 *73
00:40:48.486 : N540 G1 X108.278 Y91.722 E25.65943 *66
00:40:48.535 : N541 G1 X108.298 Y92.607 E25.70654 *69
00:40:48.622 : N542 G1 X106.702 Y94.203 E25.82667 *69
00:40:48.671 : N543 G1 X106.702 Y95.108 E25.87482 *65
00:40:48.763 : N544 G1 X108.298 Y93.512 E25.99496 *77
00:40:48.810 : N545 G1 X108.298 Y94.417 E26.04311 *64
00:40:48.891 : N546 M105 *0
00:40:48.892 : N547 G1 X106.702 Y96.013 E26.16324 *77
00:40:48.945 : N548 G1 X106.702 Y96.918 E26.2114 *116
00:40:49.031 : N549 G1 X108.298 Y95.322 E26.33153 *76
00:40:49.080 : N550 G1 X108.298 Y96.227 E26.37969 *70
00:40:49.166 : N551 G1 X106.702 Y97.823 E26.49982 *76
00:40:49.215 : N552 G1 X106.702 Y98.728 E26.54797 *66
00:40:49.375 : N553 G1 X108.298 Y97.132 E26.66811 *73
00:40:49.382 : N554 G1 X108.298 Y98.037 E26.71626 *73
00:40:49.437 : N555 G1 X106.702 Y99.633 E26.83639 *64
00:40:49.486 : N556 G1 X106.702 Y100.538 E26.88455 *121
00:40:49.572 : N557 G1 X108.298 Y98.942 E27.00468 *78
00:40:49.624 : N558 G1 X108.298 Y99.847 E27.05283 *66
00:40:49.707 : N559 G1 X106.702 Y101.443 E27.17297 *117
00:40:49.760 : N560 G1 X106.702 Y102.348 E27.22112 *120
00:40:49.842 : N561 G1 X108.298 Y100.752 E27.34125 *127
00:40:49.895 : N562 G1 X108.298 Y101.657 E27.38941 *127
00:40:49.977 : N563 G1 X106.702 Y103.253 E27.50954 *126
00:40:50.030 : N564 G1 X106.702 Y104.158 E27.5577 *75
00:40:50.112 : N565 G1 X108.298 Y102.562 E27.67783 *116
00:40:50.166 : N566 G1 X108.298 Y103.467 E27.72598 *126
00:40:50.247 : N567 G1 X106.702 Y105.063 E27.84612 *121
00:40:50.303 : N568 G1 X106.702 Y105.968 E27.89427 *125
00:40:50.468 : N569 G1 X108.298 Y104.372 E28.0144 *74
00:40:50.477 : N570 G1 E27.0144 F6000 *37
00:40:50.477 : N571 G92 E0 *100
00:40:50.522 : N572 G1 X92.913 Y91.702 F7800 *109
00:40:50.571 : N573 G1 E1 F6000 *61
00:40:50.657 : N574 G1 X91.702 Y92.913 E1.09117 F2060.95 *6
00:40:50.707 : N575 G1 X91.702 Y92.008 E1.13932 *64
00:40:50.792 : N576 G1 X92.008 Y91.702 E1.16239 *70
00:40:50.844 : N577 G1 E0.16239 F6000 *41
00:40:50.977 : N578 M117 ETE 26m 22s *96
00:40:50.977 : N579 G92 E0 *108
00:40:50.978 : N580 G1 Z0.7 F7800 *63
00:40:51.059 : N581 G1 X106.321 Y106.321 F7800 *108
00:40:51.112 : N582 G1 E1 F6000 *51
00:40:51.263 : Tisky vrstvy 3 z 50
00:40:51.264 : N583 G1 X93.679 Y106.321 E1.66048 F1030.475 *8
00:40:51.268 : N584 G1 X93.679 Y93.679 E2.32096 *71
00:40:51.333 : N585 G1 X106.321 Y93.679 E2.98145 *124
00:40:51.518 : N586 G1 X106.321 Y106.261 E3.63879 *76
00:40:51.522 : N587 G1 X105.693 Y105.693 F7800 *106
00:40:51.522 : N588 G1 X94.307 Y105.693 E4.23362 F1030.475 *8
00:40:51.526 : N589 G1 X94.307 Y94.307 E4.82845 *65
00:40:51.607 : N590 G1 X105.693 Y94.307 E5.42328 *117
00:40:51.656 : N591 G1 X105.693 Y105.633 E6.01497 *72
00:40:51.738 : N592 G1 X105.2 Y105.2 F7800 *110
00:40:51.791 : N593 G1 X94.8 Y105.2 E6.32376 F721.333 *52
00:40:51.874 : N594 G1 X94.8 Y94.8 E6.63255 *75
00:40:51.926 : N595 M105 *14
00:40:51.935 : N596 G1 X105.2 Y94.8 E6.94134 *118
00:40:52.013 : N597 G1 X105.2 Y105.14 E7.24835 *113
00:40:59.844 : N598 M105 *3
00:41:00.196 : N599 M117 ETE 26m 12s *108
00:41:08.027 : N600 M117 ETE 26m 12s *111
00:41:08.027 : N601 M105 *0
00:41:08.195 : N602 M117 ETE 26m 12s *109
00:41:08.233 : N603 G1 X105.2 Y105.6 F7800 *97
00:41:08.236 : N604 G1 X108.679 Y108.679 F7800 *98
00:41:16.255 : N605 M105 *4
00:41:16.255 : N606 M117 ETE 26m 12s *105
00:41:16.428 : N607 M105 *6
00:41:16.559 : N608 G1 X91.321 Y108.679 E8.15522 F1030.475 *0
00:41:16.564 : N609 G1 X91.321 Y91.321 E9.06208 *72
00:41:16.670 : N610 G1 X108.679 Y91.321 E9.96895 *126
00:41:16.673 : N611 G1 X108.679 Y108.619 E10.87268 *112
00:41:24.337 : N612 M117 ETE 26m 07s *104
00:41:24.337 : N613 M105 *3
00:41:24.462 : N614 M117 ETE 26m 07s *110
00:41:24.464 : N615 G1 X109.307 Y109.307 F7800 *98
00:41:25.132 : N616 G1 X90.693 Y109.307 E11.8452 F1030.475 *13
00:41:25.877 : N617 M105 *7
00:41:25.877 : N618 G1 X90.693 Y90.693 E12.81771 *118
00:41:26.627 : N619 G1 X109.307 Y90.693 E13.79023 *72
00:41:27.501 : N620 G1 X109.307 Y109.247 E14.75961 *122
00:41:27.501 : N621 G1 X109.8 Y109.8 F7800 *101
00:41:27.630 : N622 G1 X90.2 Y109.8 E15.34156 F721.333 *1
00:41:27.630 : N623 G1 X90.2 Y90.2 E15.92351 *125
00:41:28.118 : N624 G1 X109.8 Y90.2 E16.50546 *76
00:41:28.124 : N625 G1 X109.8 Y109.74 E17.08563 *70
00:41:28.752 : N626 M105 *5
00:41:28.752 : N627 G1 X109.454 Y109.6 F7800 *96
00:41:30.096 : N628 M117 ETE 25m 56s *102
00:41:30.096 : N629 G1 X108.298 Y92.008 F7800 *84
00:41:31.001 : N630 G1 X107.992 Y91.702 E17.1087 F2060.95 *54
00:41:31.869 : N631 M105 *3
00:41:31.869 : N632 G1 X107.087 Y91.702 E17.15686 *75
00:41:33.602 : N633 G1 X108.298 Y92.913 E17.24803 *69
00:41:33.609 : N634 G1 X108.298 Y93.818 E17.29618 *64
00:41:33.612 : N635 G1 X106.182 Y91.702 E17.45545 *64
00:41:33.778 : N636 G1 X105.277 Y91.702 E17.50361 *77
00:41:33.782 : N637 G1 X108.298 Y94.723 E17.73098 *66
00:41:34.765 : N638 M117 ETE 25m 55s *100
00:41:34.765 : N639 M105 *11
00:41:34.775 : N640 G1 X108.298 Y95.628 E17.77914 *64
00:41:35.789 : N641 G1 X106.702 Y94.032 E17.89927 *68
00:41:36.809 : N642 G1 X106.702 Y94.937 E17.94742 *74
00:41:37.828 : N643 M105 *6
00:41:37.875 : N644 G1 X108.298 Y96.533 E18.06756 *79
00:41:38.967 : N645 G1 X108.298 Y97.438 E18.11571 *68
00:41:40.315 : N646 M117 ETE 25m 55s *109
00:41:40.322 : N647 G1 X106.702 Y95.842 E18.23584 *70
00:41:40.325 : N648 G1 X106.702 Y96.747 E18.284 *70
00:41:41.158 : N649 M105 *12
00:41:42.248 : N650 G1 X108.298 Y98.343 E18.40413 *69
00:41:42.285 : N651 G1 X108.298 Y99.248 E18.45229 *69
00:41:42.292 : N652 G1 X106.702 Y97.652 E18.57242 *65
00:41:43.923 : N653 G1 X106.702 Y98.557 E18.62057 *73
00:41:45.680 : N654 M105 *0
00:41:45.680 : N655 M117 ETE 25m 55s *111
00:41:47.195 : N656 M105 *2
00:41:48.334 : Printer reset detected - initalizing
00:41:48.334 : start
00:41:48.435 : N1 G91 *48
00:41:48.435 : N2 G1 Z10 F100 *38
00:41:48.435 : N3 G90 *51
00:41:48.540 : N1 M110 *2
00:41:48.540 : N2 M115 *4
00:41:48.540 : N3 M105 *4
00:41:48.540 : N4 M114 *3
00:41:48.582 : N5 M111 S6 *66
00:41:48.586 : N6 T0 *28
00:41:50.960 : Info: 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000 0.000000
00:41:50.964 : Free RAM:3873
00:41:50.964 : N7 M20 *54
00:41:50.964 : N8 M80 *51
00:41:50.964 : N9 M105 *14
00:41:50.981 : N10 M220 S100 *112
00:41:50.981 : N11 M221 S100 *112
00:41:50.981 : N12 M111 S6 *116
00:41:50.982 : FIRMWARE_NAME:Repetier_0.91 FIRMWARE_URL:https://github.com/repetier/Repetier-Firmware/ PROTOCOL_VERSION:1.0 MACHINE_TYPE:Mendel EXTRUDER_COUNT:1 REPETIER_PROTOCOL:2
00:41:50.985 : Printed filament:357.73m Printing time:3 days 19 hours 7 min
00:41:50.985 : N13 T0 *40
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod HynX » 24.09.2015 16:51

Mne robilo tiez nieco podobne, asi tiez chyba s kodom m105 (uz si to nepamatam presne). Taktiez mi to sem tam odstranilo hotbed z control panela alebo udaval teplotu 500 stupnov.
Vratil som sa k Repetier-Host 1.0.6 a vsetko ide normalne.
HynX

Příspěvky: 49
Registrován: 16.01.2015 13:02
Bydliště: Martin
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 28.09.2015 07:41

no nemyslel som ze toto niekedy napisem, ale zistil som ze termistor hotbed-u som mal zapojeny o jeden pin vyssie ako je uvedene v scheme. teda medzi termistormi bol jeden volny pin. vysksual som uz vsetky verzie Repetieru no zastavuje to stale v podstate na tych istych miestach. myslite ze som tym mohol nejakym sposobom "pokazit/odpalit" RAMPS ?
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod Rebel » 28.09.2015 11:28

ramps si asi neposkodil, kazdpodadne z toho zbyleho popisu se neda nejak moc poznat. Spise mi je zahadou, co ti to mereni teploty ukazovalo/ukazuje a ze to vubec pri tom spatnem zapojeni tisklo.
V Repetier-host je graf teplot, ktery zobrazuje mereni v casove ose. Pri tisku tedy lze sledovat, jak lita teplota na HE ci HB.
Nejsem si tak uplne jist, ze by odchylka teploty pauzovala tisk, to jedine ze by delal host sam o sobe, protoze pri chybe mereni vlastniho FW se tisk zastavi a uz nepokracuje.
Dan - Rebel ? ;) - http://rebelove.org - Rebel I-III, Rebel CUBE (testuji), Anycubic i3 MEGA, Anycubic - Kossel Mini ! A naučte se používat pro STL přílohy čudlík "UMÍSTIT DO PŘÍSPĚVKU" !
Rebel

Příspěvky: 2697
Images: 243
Registrován: 12.08.2013 11:44
Bydliště: HK
Reputation: 9

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 28.09.2015 16:38

no takze velice divna vec. pripojim dole v prilohe grafy teplot. ale skusil som dnes slicovat v cura engine ci to bdue robit to iste a cuduj sa svete vytlacilo to bez jedineho zastavenia. zaujimave ako by ste postupovali naistalovat osobitne slicer alebo velmi dobre hlbkovo ho odinstalovat? registre atd. alebo nejake napady?
Nemáte oprávnění prohlížet přiložené soubory.
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 30.09.2015 16:27

prosim vas bol by niekto ochotny uploadnut mi nastavenie vasho sliceru z repetiera? daju sa nastavenia erxportovat tak ak by z vas niekto chcel. dakujem
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod blizzy » 02.10.2015 20:19

petrik píše:prosim vas bol by niekto ochotny uploadnut mi nastavenie vasho sliceru z repetiera? daju sa nastavenia erxportovat tak ak by z vas niekto chcel. dakujem

Tez bych poprosil o nastaveni ABS i PLA - nejak se v tom topim pri prochazeni netu. Tez predem dekuji
blizzy

Příspěvky: 27
Registrován: 02.10.2015 19:09
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 14.10.2015 14:25

ok. takze opat tlacim. chyba ktoru som opisoval na zaciatku vlakna bola ani neviem kde. ked som vypisal v sliceri nove nastavenia a ulozil som si ich pod novy profil tak to zacalo tlacit bez zastavovania a sekania.
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 29.10.2015 10:09

prosim vas co sa da robit s tymto ak vam to vybehne v repetiery? myslim tu oranzovu tabulku vpravo
Nemáte oprávnění prohlížet přiložené soubory.
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod JCHP » 29.10.2015 10:24

Udělat ten model znova, lépe a radostněji..
Nebo ho prohnat nějakým programem, co umí ty díry a nespojitosti zalátat.
Upravený Kossel Clear s výměnnými hlavami (J-head a celokov s vodním chlazením)
JCHP

Příspěvky: 175
Images: 4
Registrován: 03.09.2014 12:06
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod Pezantros » 29.10.2015 10:31

Na tohle je dobry program netfabb Basic. Je volně ke stažení. Tutoriál, jak na to, je zde https://www.youtube.com/watch?v=bR51LS5pN34. Jinak někdy pomůže i kliknout nad tou oranžovou poznámkou na ikonu ozubeného kola a tam na tlačítko Opravit normály.
Naposledy upravil Pezantros dne 29.10.2015 10:37, celkově upraveno 1
Pezantros

Příspěvky: 185
Registrován: 19.04.2015 12:22
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod Rebel » 29.10.2015 10:35

Pezantros byl rychlejsi, ale kdyz uz jsem to napsal :D >>>

Ono to je v tom okynku napsany. Stahni si Netfabb studio Basic, model v nem otevri a pouzij opravu. V te Basic verzi nejdou vsecky, ale vetsinou to staci a zbytek (Opravit normaly) se da vetsinou primo v Repetieru, pod tou ikonkou ozubenyho kolecka u modelu v seznamu v pravo.
Dan - Rebel ? ;) - http://rebelove.org - Rebel I-III, Rebel CUBE (testuji), Anycubic i3 MEGA, Anycubic - Kossel Mini ! A naučte se používat pro STL přílohy čudlík "UMÍSTIT DO PŘÍSPĚVKU" !
Rebel

Příspěvky: 2697
Images: 243
Registrován: 12.08.2013 11:44
Bydliště: HK
Reputation: 9

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 29.10.2015 11:11

opravit normaly som skusal, no ten text v oranzovom poli som si neprecital cely dakujem za reakcie a vysvetlenie takze to vyskusam dam vediet ako to dopadlo. a k modelu len tolko ze je to stiahnuty model z thinverse a vieme ze *.stl sa da dost tazko resp. vobec upravovat. aby sme boli presny tak da sa http://mech.fd.cvut.cz/presentation/oth ... workbench/
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod Rebel » 29.10.2015 11:25

Kdyz sem posles ten model, nebo odkaz na nej, zkusim ho opravit. Oprava normal je az to posledni, co se da pouzit. Vetsinou je chyba v nespojitosti polygonu a po jejich oprave se obcas musi jeste opravit ony normaly, coz nevim co je, ale funguje to :D
Dan - Rebel ? ;) - http://rebelove.org - Rebel I-III, Rebel CUBE (testuji), Anycubic i3 MEGA, Anycubic - Kossel Mini ! A naučte se používat pro STL přílohy čudlík "UMÍSTIT DO PŘÍSPĚVKU" !
Rebel

Příspěvky: 2697
Images: 243
Registrován: 12.08.2013 11:44
Bydliště: HK
Reputation: 9

Re: rebel II zastavuje pocas tlace aneb moje tazkosti s rebe

Příspěvekod petrik » 03.11.2015 08:50

diky za pomoc takze nechal som to opravit v netfabb Basic a uz to vyzera v poriadku. este raz dik
petrik

Příspěvky: 63
Registrován: 01.03.2015 13:18
Bydliště: BA III / Slovensko
Reputation: 0

Další

Zpět na REBEL II

Kdo je online

Uživatelé procházející toto fórum: Žádní registrovaní uživatelé a 2 návštevníků
